VW Beetle Front Fresh Air & Defroster Systems

1955-65 VW Beetle Front Defroster Diagram

1966-67 VW Beetle Front Defroster Diagram

1968 VW Beetle Front Defroster Diagram

1969-70 VW Beetle Front Defroster Diagram

1971-77 VW Beetle Front Defroster Diagram

1971-72 VW Super Beetle Front Defroster Diagram

1973-79 VW Super Beetle Front Defroster Diagram

Available Parts for 1955-65 Beetle:

• 113819723A - 32mm Defroster Hose.

---

Available Parts for 1966-67 Beetle:

• 211255359 - 26mm Center Defroster Hose.
• 113819723A - 32mm Side Defroster Hose.
• 113819723 - 38mm Y-Connector Defroster Hose.
• 111255483 - Center Dash Vent.

---

Available Parts for 1968 Beetle:

• 111819543 - 20mm Fresh Air Box Drain Hose.
• 211255359 - 26mm Center Defroster Hose.
• 113819723A - 32mm Side Defroster Hose.
• 113819723 - 38mm Y-Connector Defroster Hose.
• 113819717 - 47mm Fresh Air Box Hose (pre-cut).
• 113-483 - Center Dash Vent.
• 113-719A-L-R - Side Dash Vents.

---

Available Parts for 1969-70 Beetle:

• 111819543 - 20mm Fresh Air Box Drain Hose.
• 211255359 - 26mm Center Defroster Hose.
• 113819723A - 32mm Side Defroster Hose.
• 113819717 - 47mm Fresh Air Box Side Hose.
• 133819365 - 47mm Heater Channel to Y-Connector Hose.
• 113-483 - Center Dash Vent.
• 113-719A-L-R - Side Dash Vents.

---

Available Parts for 1971-77 Beetle:

• 111819543 - 20mm Fresh Air Box Drain Hose.
• 211255359 - 26mm Center Defroster Hose.
• 113819723A - 32mm Side Defroster Hose.
• 133819365 - 47mm Heater Channel to Y-Connector Hose.
• 211261235A - 55mm Fresh Air Box Side Hose.
• 113-483 - Center Dash Vent.
• 113-635A-L-R - Side Dash Vents (Top Facing).
• 113-745 - Side Dash Vent (Front Facing Left).
• 113-746 - Side Dash Vent (Front Facing Right).

    *63mm Hose is not available. We modified 55mm hose to make this work. **See this video for example.

---

Available Parts for 1971-73 Super Beetle:

• 211255359 - 26mm Center Defroster Hose.
• 113819723A - 32mm Side Defroster Hose.
• 133819365 - 47mm Heater Channel to Y-Connector Hose.
• 211261235A - 55mm Fresh Air Box Side Hose.
• 113-635A-L-R - Side Dash Vents (Top Facing).
• 113-745 - Side Dash Vent (Front Facing Left).
• 113-746 - Side Dash Vent (Front Facing Right).

    *63mm Hose is not available. We modified 55mm hose to make this work. **See this video for example.

---

---
