Replacement Electronic Ignition for PerTronix Flame Thrower Vacuum Advance Distributor

  • Increased voltage to your spark plugs for longer spark plug life
  • More horsepower and better fuel economy vs. points and a condenser
  • No moving parts to wear out
  • Sealed for protection against dirt, oil, grease and moisture
  • Stable timing for a "set it and forget it" ignition timing adjustment

The replacement Pertronix Flame Thrower SVDA Distributor Ignitor 1 Electronic Ignition Module can be used with any Pertronix replacement VW SVDA Flamethrower distributor to replace a burnt out unit. This is a direct replacement for the module in the PTD186504 distributor but be used in the D7182504 (Ignitor 3) or D189504 (6 volt) units to replace their units with this 12 volt, Ignitor 1 module.

A coil with 3 to 4.2 ohms of resistance is required with the Pertronix Ignitor Ignition Module. Pertronix recommends the 40611 or PT40501 coil, available separately in the Additional Options tab above.

Also note, Suppression or Spiral wound spark plug wires must be used with the Ignitor, solid core plug wires will cause electronic interference!



Unless you have a tachometer (gauge), the distributor should be the only item connected to the negative (“1” or “-“) side of the ignition coil.

Distributor with Points

Distributor Diagram for Points

If your distributor only has one (most commonly green) wire, it has points and a condenser. Connect the wire from the condenser to the negative side of the coil.

Distributor with Electronic Ignition

Distributor Diagram for Electronic Ignition

If your distributor only has two wires (most commonly a black and a red wire) it has an electronic ignition. Connect the black wire from the electronic ignition to the negative side of the coil. The red wire from the electronic ignition will connect to the positive side (“15” or “+“) of the coil. Most importantly - the coil will have other black wires on the positive side which are “key hot” wires. It may look odd, but hooking up the black wire from the electronic ignition with the other black wires on the positive side of the coil will fry the electronic points.

(Note, the negative connection on the coil should never be connected to ground. Doing so will ground out the coil and it will not operate.)


California Prop 65 Warning: Cancer and Reproductive Harm
Please Note:The information listed below is for stock, unmodified VW's manufactured for sale in the US. VW's are commonly modified and very often parts from another year VW may have been installed on your car. California Pacific JBugs is not responsible for any errors if your car has been modified in any way.
VW Beetle
Sedan
1954 - 1977
Ragtop
1954 - 1963
Sunroof
1964 - 1977
Convertible
1954 - 1970
VW Super Beetle
Sedan
1971 - 1975
Convertible
1971 - 1979
VW Karmann Ghia
Coupe
1956 - 1974
Convertible
1957 - 1974
VW Type II (Bus)
Bus
1955 - 1979
Single Cab
1955 - 1979
Double Cab
1958 - 1979
1981 - 1982
VW Type 3
Squareback
1962 - 1973
Notchback
1962 - 1973
Fastback
1966 - 1973
VW Thing
Thing
1973 - 1974
VW Vanagon
Vanagon
1980 - 1991
