VW Tech Article: Front Beam, Link Pin 1960-65
Link Pin Front End for 1960.5-1965 Type 1
Link Pin front ends were originally found on early VW Beetles through 1965. 1954-1960.5 did not use steering dampers while 1960.5-1965 did. Always check part description to make sure it is compatible with your vehicle.• 1954-62 Link Pin Front ends use 10mm upper shock bolts.
• 1963-65 Link Pin Front ends use 12mm upper shock bolts.
| Number | Image | Product Code | Description | Cart |
|---|---|---|---|---|
| 1 |
|
131415811 | Tie Rod End - Right Outer | |
| 2 |
|
113415802B | Right Side Tie Rod Assembly | |
| 3 |
|
113415813 | Tie Rod End - Right Inner | |
| 4 |
|
113415821-OC | Tie Rod End - Left Inner | |
| 5 |
|
113415801 | Left Side Tie Rod Assembly | |
| 6 |
|
131415811 | Tie Rod End - Left Outer | |
| 7 |
|
17-2565 | 1954-61 Type 1 Pitman Arm Chrome | |
| 7 |
|
17-2565-B | 1954-61 Type 1 Pitman Arm Black |
|
| 7 |
|
17-2566 | 1962-68 Type 1 Pitman Arm Chrome | |
| 7 |
|
17-2566-B | 1962-68 Type 1 Pitman Arm Black | |
| 7 |
|
111415385 | 1954-77 Pitman Arm Lock Plate | |
| 8 |
|
111498021 | King Pin Set - German - 1946-65 Beetle | |
| 9 |
|
22-2976 | Spindles | |
| 10 |
|
111498051A | Link Pin Set - German - 1946-65 Beetle | |
| 11 |
|
9593 | Sway Bar Mounting Kit for 3/4" Bar | |
| 12 |
|
9596 | Sway Bar - 3/4" - Front Link Pin |
|
| 13 |
|
98-4166-B | Torsion Bar Grub Screw | |
| 14 |
|
98-4165-B | Grub Screw Nut | |
| 15 |
|
111-129 | Front Trailing Arm Grease Seals | |
| 16 |
|
111401301 | Control Arm Bearing - Outer Front | |
| 17 |
|
413030 | Torsion Leaves - Stock Width |
|
| 18 |
|
N185161 | Grease Zerk Fitting | |
| 19 |
|
22-2816 | Front Beam Bolts - Pair | |
| 20 |
|
22-2812 | Adjustable Link Pin Beam | |
| 21 |
|
113415061C | Steering Box | |
| 22 |
|
113-115 | 17mm Shock Pads |
|
| 23 |
|
111-123A | Body to Front Beam Shock Pads | |
| 24 |
|
17-2584 | Steering Box and Shaft Coupler | |
| 25 |
|
111415417 | Steering Coupler Disc | |
| 26 |
|
9656 | Performance Gas Shock - Front Link Pin | |
| 27 |
|
111-273 | Front Suspension Stops - Pair | |
| 28 |
|
111413401A | 1952-64 Shock Absorber Bolt - Upper Front - 12mm shouldered bolt with 10mm Thread | |
| 29 |
|
111413403A | 1963-65 Shock Absorber Bolt - Upper Front - 12mm shouldered bolt with 12mm Thread | |
| 30 |
|
113425021 | Steering Damper |
